Interactive Set-Up
AX3000 Models 80 and 85 - User's Manual 53
3.4.4 - Connecting a Mouse
A USB mouse is automatically detected by the Axel thin client. No specific settings are required.
Note: multiple mice (USB and/or PS2) can be used simultaneously.
3.4.5 - Connecting a HUB
A USB HUB is automatically detected by the Axel thin client. No specific settings are required.
3.4.6 - Connecting a Printer
a) Logical Port Attachment
When a USB printer is connected for the first time to the Axel thin client a logical port is associated.
Four logical ports are available: Usb1, Usb2, Usb3 and Usb4.
The associated logical ports are listed in the menu [Configuration]-[Ports]-[USB Logical Ports].
To get information of a USB printer, select its logical port. For example:
This association is maintained even if the printer is powered off, disconnected or connected to the
other USB port.
Releasing a logical port is a manual operation (see Chapter below 'Releasing a Logical Port').
b) Setting-Up
The USB printer set-up procedure is the same as a serial or parallel printer.
For more information, see Chapter 3.5.2 and the following.
c) Releasing a Logical Port
A logical port must be manually released. This operation can be performed only when the USB
device is no longer connected.
