Page #152 background image
Installing under OS/390
142 AX3000 Models 80 and 85 - User's Manual
7.2 - USING THE TERMIMAL
7.2.1 - The 3270 Status Line
Note: the 3270 status line is different than the AX3000 TCP/IP status line.
The 3270 status line is displayed at the bottom of the screen and gives the following information:
Connection status Shift/Caps Function key Assignment
Keyboard indicators Insert
SA X () ^ R 64    LL/CC
Connection type: (application) Available Keystrokes Cursor
? (system) Mode: R (Record) Locator
P (Process)
The status symbols are described in the following tables.
Connection Symbols
Symbol
Meaning
S
Connection with host is established
A
Connection is non-SNA
Connection to an application (Lu-Lu)
?
Connection to the system (not an application)
