Barco RLM series User Manual

3. Advanced Commands
Receive (acknowledge)
Start
\xfe
Projector address
\x01
Command[0]
\x00
Command[1]
\x06
Checksum
\x07
Stop
\xff
3.2.12 PiP remove Layout
Description
Removes a PiP layout.
Command
Command [0]
\x12
Command [1]
\x0a
Data
strPipname1
...
strPipnameN
The strPipn ameN string is of the C-lang ua ge type. s ee chapter "1. S erial commu nic ations Basics", "Syntax",
page 9
Wildcards can be u sed to specify strPipnameN .see "Syntax", page 9
Example
Removes the PiP layout “test”.
Transmit
Start
\xfe
Projector address
\x01
Command[0]
\x12
Command[1]
\x0a
Data[0]
\x74
Data[1]
\x65
Data[2]
\x73
Data[3]
\x74
Data[4]
\x00
Checksum
\xdd
Stop
\xff
Receive (acknowledge)
Start
\xfe
Projector address
\x01
R5976884 RLM SERIES 04/04/2006 99
