2. Basic Commands
Command
Command [0]
\x63
Data
Data[0] = unsigned byte
data value: 1= lamp1 ; 2=lamp2
Returned Data
string = Pascal-language string.
2.31 Image f iles
2.31.1 File, write
Description
This command writes an image f
iletotheprojector,thiscanbeusedtowritetotheprojectorapreviouslybackedupfile(onPC)
which has been read with the “file, read” command.
The string used to represent the filename is of the C-string type.
Command
Command [0]
\xbe
Data
strFilename = string of the C-string type representing the filename: Example of filename : HD_1080P@60.xml
By default the file will be selected in the Custom direct ory. If the necessary file is a standard file then strFile-
name should be /Stan dard /HD_1 080@60.xml.
FileData = data (ASCII coded) in XML format representing the file.
Example of FileData for the HD_1080P@ 60. xml file :
<?xml version="1.0" encoding="UTF-8" ?>
<ImageFile>
<FileSelection>
<InputLayer />
<SourceType />
<LineDuration Discrepancy="220" Unit="ns">14840</LineDuration>
<TotalLines Discrepancy="1">1118</TotalLines>
<Interlaced>no</Interlaced>
</FileSelection>
<ImageDefinition>
<TotalPixels>2536</TotalPixels>
<ActivePixels>1920</ActivePixels>
<PixelStart>380</PixelStart>
<ActiveLines>1080</ActiveLines>
<LineStart>31</LineStart>
<AspectRatio>16:9</AspectRatio>
<ColorSpaceFormat>ITU.BT-601</ColorSpaceFormat>
</ImageDefinition>
</ImageFile>
The data must be XML “valid” i.e. all the rules (for example for opening/clo sin g tags) must be respected.
R5976884 RLM SERIES 04/04/2006 67
