Barco RLM series User Manual

2. Basic Commands
bit5 gives an in dication on wheth er the projector can be (re)started or not (hot restrike), if the cool down cycle
is active (bit5 = 0) the projector can not be restarted until the cool dow n cycle has been completed.
Example
Read the status being : \x23:
•projectorisON
• textbox is on
• cool down cycle is inactive
Transmit
Start
\xfe
Projector address
\x01
Command[0]
\x67
Checksum
\x68
Stop
\xff
Receive (acknowledge)
Start
\xfe
Projector address
\x01
Command[0]
\x00
Command[1]
\x06
Checksum
\x07
Stop
\xff
Receive (Awnser)
Start
\xfe
Projector address
\x01
Command[0]
\x67
Data[0]
\x23
Checksum
\x8b
Stop
\xff
2.6 Lens commands
2.6.1 Lens shift
Description
Shifts the lens down or up depending on t
he data sent.
Command
Command [0]
\xf4
Command [1]
\x81
20 R5976884 RLM SERIES 04/04/2006
