Barco RLM series User Manual

3. Advanced Commands
Receive (acknowledge)
Command[0]
\x00
Command[1]
\x06
Checksum
\x07
Stop
\xff
3.2.13 PiP remove window
Description
Removes a particular PiP window .
Command
Command [0]
\x12
Command [1]
\x0b
Data
Data [0] = Window type byte
Window type byte value:
0=DataA;1=VideoA;2=DataB;3=VideoB
Example
Removes a particular PiP window , here: \x01 (Data A )
Transmit
Start
\xfe
Projector address
\x01
Command[0]
\x12
Command[1]
\x0b
Data[0]
\x01
Checksum
\x1f
Stop
\xff
Receive (acknowledge)
Start
\xfe
Projector address
\
x01
Command[0]
\x
00
Co
mmand[1]
\x06
Checksum
\x07
Stop
\xff
3.2.14 Addable sources List, read
Description
This command reads a list of the sources which can be added to the PiP using the “add window” command.
100
R5976884 RLM SERIES 04/04/2006
