Barco RLM series User Manual

3. Advanced Commands
Command
Command [0]
\x12
Command [1]
\x0d
Returned Data
strSourceName1
...
strFilenameN
3.2.15 PiP add window
Description
Adds a PiP window .
To add a window following have to be specified:
• source to be visualized in the window
• Mode of the source input
• position and size of the window
• order (priority) of the window (front, background)
Command
Command [0]
\x12
Command [1]
\x0c
Data
Data[0] = bySource, byte describing the source to be linked to the window.
Byte value
source
1
BNC’s
2 D15
3
Composite video
4
SVideo
5
DVI
6 Firewire
7
SDI
8
PC
Data[1] = byMode, byte describing the signals connected to the input section.
For more info about the input configurations, see the projector’s Owner’s manual.
for BNC’s and D15:
Byte value Mode
0
RGBHV
1
RGBCS (analog)
2
RGBCS (digital)
3
RG
s
B
4 PrYPb
255 detect slot mode
R5976884 RLM SERIES 04/04/2006 101
