Barco RLM series User Manual

3. Advanced Commands
Read clamp width
Command [0]
\x21
Command [1]
\x68
Returned Data
Commands
Data type
total lines
unsigned word (2 bytes)
active lines
unsigned word (2 bytes)
line start
unsigned word (2 bytes)
period
unsigned word (2 bytes)
total pixels
unsigned word (2 bytes)
active pixels
unsigned word (2 bytes)
pixel start
unsigned word (2 bytes)
clamp width unsigned byte
3.31.7 Image files settings,Increment
Description
These commands set the image files characterisitics
Commands
Increment total lines:
Command [0]
\x22
Command [1]
\x58
Increment active lines
Command [0]
\x22
Command [1]
\x59
Increment line start
Command [0]
\x22
Command [1]
\x5a
Increment period
Command [0]
\x22
Command [1]
\x5b
Increment total pixels
Command [0]
\x22
Command [1]
\x5c
Increment active pixels
Command [0]
\x22
Command [1]
\x5d
146 R5976884 RLM SERIES 04/04/2006
