3. Advanced Commands
Transmit
Checksum
\x14
Stop
\xff
3.2.2 PiP Focus, Read
Description
Returns the PiP window which has the focus.
Command
Command [0]
\x12
Command [1]
\x02
Returned Data
Data [0] = Window type byte
Window type byte value:
0=DataA;1=VideoA;2=DataB;3=VideoB
Example
Read the PiP window which has the focus, result = \x01 (Data A )
Transmit
Start
\xfe
Projector address
\x01
Command[0]
\x12
Command[1]
\x02
Checksum
\x15
Stop
\xff
Receive (acknowledge)
Start
\xfe
Projector address
\x01
Command[0]
\x00
Command[1]
\x06
Checksum
\x07
Stop
\x
ff
Re
ceive (Awnser)
Start
\xfe
Projector address
\x01
Command[0]
\x12
Comma
nd[1]
\x02
Data [
0]
\x01
90 R5976884 RLM SERIES 04/04/2006
