Barco RLM series User Manual

3. Advanced Commands
Note that the panel size (projector ve rs ion ) can be read using the Panel size command
3.2.29 PiP Window vertical position, Read Min/Max
Description
Reads the minimum/maximum value for the window vertical position adjustments in PiP.
Commands
read minimum:
Command [0]
\x26
Command [1]
\x95
read maximum:
Command[0]
\x27
Command[1]
\x95
Returned Data
Data[0]...Data[3] = signed double word Yposition : describes the min/max “heigth” of the window (y axis).
Note that the panel size (projector ve rs ion ) can be read using the Panel size command
3.2.30 PiP Priority Write
Description
Sets the priority (order) of a particular window
Command
Command [0]
\x12
Command [1]
\x0e
Command [2]
1,2,3
Command [2] : 1= Top ; 2 = bring to front ; 3 = send to back
Data
Data [0] = Window type byte
Window type byte value:
0=DataA;1=VideoA;2=DataB;3=VideoB
Example
Brings the Data A window to the front
Transmit
Start
\xfe
Projector address
\x01
110 R5976884 RLM SERIES 04/04/2006
