Barco RLM series User Manual

3. Advanced Commands
Command
Command [0]
\x21
Command [1]
\x92
Returned Data
Data[0]...Data[3] = signed double word XPosition
: describes the start position of the window (x axis).
Data[4]...Data[7] = signed double word YPosition : describes the start position of the window (y axis).
Data[8]...Data[11] = signed double word Xsize : describes the “width” of the window (x axis).
Data[12]...Data[15] = signed double word Ysize : describes the “height” of the window (y axis).
Xsize, Ysize are given in “p ixels”
3.2.22 PiP Window free size, Read Min/Max
Description
Reads the minimum/maximum value for
the window free size adjustments in PiP.
Commands
read minimum:
Command [0]
\x26
Command [1]
\x92
read maximum:
Command[0]
\x27
Command[1]
\x92
Returned Data
Data[1]...Data[4] = signed double word XPosition : describes the min/max start position of the window (x axis).
Data[5]...Data[8] = signed double word YPosition : describes the min/max start position of the window (y axis).
Data[9]...Data[12] = signed double word Xsize : describes the min/max “width” of the window (x axis).
Data[13]...Data[16] = signed double word Ysize : describes the min/max “height” of the window (y axis).
Note that the panel size (projector ve rs ion ) can be read using the Panel size command
3.2.23 Window horizontal position, Write
Description
This command sets the horizontal position of the active window.
106
R5976884 RLM SERIES 04/04/2006
