Barco RLM series User Manual

2. Basic Commands
Transmit
Command[0]
\x20
Command[1]
\x9a
Data[0]
\x01
Checksum
\xbc
Stop
\xff
Receive (acknowledge)
Start
\xfe
Projector address
\x01
Command[0]
\x00
Command[1]
\x06
Checksum
\x07
Stop
\xff
2.36 Switching mode, Read
Description
Reads the Switching Mode of the projector
Command
Command [0]
\x21
Command [1]
\x9a
Returned Data
Data [0] = unsigned byte
Byte value
Switching mode
\x01
Seamless
\x02
Box in
\x03
Box out
\x04
shift in left
\x05
shift in right
\x06
shift in top
\x07
shift in bottom
\x08
vertical curtain open
\x09
vertical curtain close
\x0a
Horizontal curtain open
\x0b
Horizontal curtain close
\x0c
Fade in out
R5976884 RLM SERIES 04/04/2006 75
