Barco RLM series User Manual

3. Advanced Commands
Receive (Awnser)
Checksum
\x16
Stop
\xff
3.2.3 PiP Focus, Write
Description
Gives the focus to a particular PiP window .
Command
Command [0]
\x12
Command [1]
\x03
Data
Data [0] = Window type byte
Window type byte value:
0=DataA;1=VideoA;2=DataB;3=VideoB
Example
Gives the focus to a particular PiP window , here: \x01 (Data A )
Transmit
Start
\xfe
Projector address
\x01
Command[0]
\x12
Command[1]
\x03
Checksum
\x16
Stop
\xff
Receive (acknowledge)
Start
\xfe
Projector address
\x01
Command[0]
\x00
Command[1]
\x06
Checksum
\
x07
S
top
\xff
3.2.4 PiP layout , Read
Description
Returns the configuration of a particular layout.
Command
Command [0]
\x12
Command [1]
\x0f
R5976884 RLM SERIES 04/04/2006 91
