2. Basic Commands
Transmit
Data [4]
\x2e (=’.’)
Data [5]
\x63 (=’c’)
Data [6]
\x30 (=’0’)
Data [7]
\x35 (=’5’)
Data [8]
\x00
Checksum
\xF6
Stop
\xff
Receive (Acknowledge)
Start
\xfe
Projector Address
\x01
Command [0]
\x00
Command [1]
\x06
Checksum
\x07
Stop
\xff
2.13 Orientation, Write
Description
Writes the orientation to the projector
Command
Command [0]
\x20
Command [1]
\x24
Data
Data [0] = unsigned byte
byte value:
\x00 =rear/table;\x40 = fron t/t able ; \x80 = front/ceiling ; \xc0 = rear/ceiling
Example
Set the orientation to front/table.
Transmit
Start
\xfe
Projector address
\x01
Command[0]
\x20
Command[1]
\x24
Data[0]
\x40
R5976884 RLM SERIES 04/04/2006 49
