Barco RLM series User Manual

2. Basic Commands
Command
Command [0]
\xf5
Data (optional)
Data[0] = byWindow
Data[1], Data[2] = wValue = word describing the settings of the AutoImage function
The 4 bits of the first byte (lsb) are used.
bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
- - - -
Start pixel-line
Phase
Contr/Bright
Tot a lP ixe ls
Table 2-264
byte description
Example
executes Autoimage on the window which has the focus (the data bytes are ommited).
Transmit
Start
\xfe
Projector address
\x01
Command[0]
\xf5
Checksum
\xf6
Stop
\xff
Receive (acknowledge)
Start
\xfe
Projector address
\x01
Command[0]
\x00
Command[1]
\x06
Checksum
\x07
Stop
\xff
2.41 Blanking
Overview
• Blanking Reset
• Blanking enable, Write
• Blanking enable, Read
• Blanking, Write
• Blanking, Read
• Blanking, Increment
• Blanking, Decrement
• Minimum Blanking, Read
• Maximum Blanking, Read
R5976884 RLM SERIES 04/04/2006
79
