Barco RLM series User Manual

3. Advanced Commands
Command
Command [0]
\x12
Command [1]
\x11
Returned Data
Returned data is 4 times following data :
Data [0] = Window type byte ; 0 = Data A ; 1 = Video A ; 2 = Data B ; 3 = Video B
Data [ 1] = Window visible byte ; 0 = NO ; 1 = YES
Data [2] = file found byte ; 0 = NO ; 1 = YES
Data [3] = input selection byte
for video windows : 0 = decoder layer1; 1 = decoder layer3 ; 4 = SDI ; 0xff = None
for data windows : 0 = data ; 1 = SBC ; oxff = None
Data [4] = source selection word
for video windows
word value
Source
0 video
1
VS
2 R
3
G
4 B
5
Lum
6
Chr
7
Video2
20
PrYPb on RGB
21
RGB video on RGB
22
RG
s
B video on RGB
100
S-video
101
S-Video2
102
S-Video3
103
S-Video4
300
SDI
0xff
none
for data windows:
word value
source
0
RGBHV
1
RGBC
S
(digital)
2
RGBC
S
(analog)
6
3
RG
S
B
100 DssPryPb
6. the signal present on the Cs signal is a composite video signal containing the composite sync
112 R5976884 RLM SERIES 04/04/2006
