Barco RLM series User Manual

3. Advanced Commands
Commands
Black input balance Red
Command [0]
\x21
Command [1]
\x84
Black input balance Green
Command [0]
\x21
Command [1]
\x85
Black input balance Blue
Command [0]
\x21
Command [1]
\x86
Read Data
Data [0] = lsb
Data [1] = msb
Example
Reads the black input balance for Red, being \x10
Transmit
Start
\xfe
Projector address
\x01
Command[0]
\x21
Command[1]
\x84
Checksum
\xa6
Stop
\xff
Receive (acknowledge)
Start
\xfe
Projector address
\x01
Command[0]
\x00
Command[1]
\x06
Checksum
\x07
Stop
\xff
Receive (Awnser)
Start
\xfe
Projector address
\x01
Command[0]
\x21
Command[1]
\x84
Data [0]
\x10
Data [1]
\x00
R5976884 RLM SERIES 04/04/2006 129
