Menu list
PRESS RIGHT KEY FOR
Issue: 5.12
ENTRY MENU LEVEL 1
CHANGE PARAMETERS 2
RUN MODE RAMPS 3
........2 1)RA MP OP MONIT OR = 0.0 0 %
........2 2)FORW ARD UP TIME = 10.0 SECS
........2 3)FORW ARD DO W N TIME = 10.0 SECS
........2 4)REVERSE UP TIME = 10.0 SECS
........2 5)REVERSE D O W N TIME = 10.0 SECS
........2 6)RA MP INPUT = 0.00 %
........2 7)FORW ARD MIN SPEED = 0.00 %
........2 8)REV ERSE MIN SPEED = 0.0 0 %
........2 9)RAMP A UTO PRESET = ENABLED
........3 0)RAMP EXT PRESET = DIS A BLED
........3 1)RA MP PRESET V ALUE = 0.00 %
........3 2)RA MP S-PROFILE % = 2.50 %
........3 3)RA MP H OLD = DISABLED
........3 4)RA MPING THRESH OLD = 0.50 %
........3 5)RA MPING FLA G = LOW
JOG CRAWL SLACK 3
........3 7)JO G SPEED 1 = 5.00 %
........3 8)JO G SPEED 2 = -5.00 %
........3 9)SL A C K SPEED 1 = 5.0 0 %
........4 0)SL A C K SPEED 2 = -5.00 %
........4 1)CRA WL SPEED = 10.00 %
........4 2)JO G MODE SELECT = LO W
........4 3)JO G/SL A CK RA MP = 1.0 SECS
MOTORISED POT RAMP 3
........4 5)MP OP MONITOR = 0.0 0 %
........4 6)MP UP TIME = 10.0 SECS
........4 7)MP DOWN TIME = 10.0 SEC S
........4 8)MP UP C O M M A ND = DIS A BLED
........4 9)MP DOWN COMM A ND = DISABLED
........5 0)MP M AX CLA MP = 1 00.00 %
........5 1)MP MIN CLA MP = -10 0.00 %
........5 2)MP PRESET = DIS A BLED
........5 3)MP PRESET V ALUE = 0.00 %
........5 4)MP MEMORY BO O T-UP = DIS A BLED
STOP MODE RAMP 3
........5 6)S T OP RA MP TIME = 1 0.0 SEC S
........5 7)S T OP TIME LIMIT = 60.0 SECS
........5 8)LIV E DELA Y M O DE = DIS A BLED
........5 9)DROP-OUT SPEED = 2.00 %
........6 0)DROP-OUT DEL A Y = 1.0 SEC S
SPEED REF SUMMER 3
........6 2)INT SPEED REF 1 = 0. 00 %
........6 3)SPEED REF 2 = 0.0 0 %
........6 4)SPEED REF 3 M O N = 0.0 0 %
........6 5)RA MPED SPD REF 4 = 0.00 %
........6 6)SPD/CUR REF3 SIGN = N O N-IN VERT
........6 7)SPD/CUR RF3 RA TIO = 1.0000
SPEED CONTROL 3
........6 9)M A X POS SPEED REF = 105.0 0 %
........7 0)M A X NEG SPEED REF = -1 05.00 %
........7 1)SPEED PROP G AIN = 1 5.00
........7 2)SPEED INT T.C . = 1.00 0 SEC S
........7 3)SPEED INT RESET = DISABLED
SPEED PI ADAPTION 4
.......... 7 4)SPD A DPT LO BRPNT = 1.00 %
.......... 7 5)SPD A DPT HI BRPNT = 2.00 %
.......... 7 6)LO BRPNT PRP G AIN = 5.0 0
.......... 7 7)LO BRPNT INT T.C. = 1.000 SECS
.......... 7 8)IN T % DURING RA MP = 10 0. 00 %
.......... 7 9)SPD A D A PT EN A BLE = EN ABLED
CURRENT CONTROL 3
........8 1)CUR CLA MP SC ALER = 150.00 %
CURRENT OVERLOAD 4
.......... 82)O/LO A D % T ARGET = 105.0 0 %
.......... 83)O/LO A D RA MP TIME = 20.0 SECS
I DYNAMIC PROFILE 4
.......... 84)I PROFILE ENABLE = DIS ABLED
.......... 85)SPD BRPNT A T HI I = 75.00 %
.......... 86)SPD BRPNT A T LO I = 1 00.00 %
.......... 87)CUR LIMIT A T L O I = 1 00.00 %
........8 8)DU AL I CL A MP ENBL = DISABLED
........8 9)UPPER CUR CL A MP = 0.00 % #
........9 0)LOWER C UR CLA MP = 0. 00 % #
........9 1)E X TRA C UR REF = 0.00 %
........9 2)A UTOTUNE ENABLE = DIS A BLED
........9 3)CUR PROP GAIN = 30.00
........9 4)CUR INT G AIN = 3.00
........9 5)CUR DISCONTINUITY = 13.00 %
........9 6)4-QUA DRA NT MODE = ENABLED
........9 7)SPD BYPASS CUR EN = DISABLED
FIELD CONTROL 3
........9 9)FIELD EN A BLE = ENABLED
........1 0 0)FIELD VOLTS OP % = 90.0 0 %
........1 0 1)FIELD PROP GAIN = 1 0
........1 0 2)FIELD INT GAIN = 1 00
FLD WEAKENING MENU 4
.......... 1 03)FLD WE A K EN A BLE = DIS ABLED
.......... 1 04)FLD WK PROP G AIN = 50
.......... 1 05)FLD WK INT TC ms = 4 000
.......... 1 06)FLD WK DRV TC ms = 20 0
.......... 1 07)FLD WK FB DRV ms = 100
.......... 1 08)FLD WK FB INT ms = 100
.......... 1 09)SPILLOVER A V F % = 100.0 0 %
.......... 1 10)MIN FLD CURRENT = 10.00 %
........1 1 1)ST A NDBY FLD ENBL = DIS A BLED
........1 1 2)ST A NDBY FLD C UR = 25.0 0 %
........1 1 3)FLD QUENCH DELA Y = 10.0 SEC S
........1 1 4)FIELD REFERENCE = 100.00 %
ZERO INTERLOCKS 3
........1 1 5)ST A NDSTILL ENBL = DIS ABLED
........1 1 6)ZERO REF ST ART = DIS A BLED
........1 17)ZERO INTLK SPD % = 1.0 0 %
........1 18)ZERO INTLK C UR % = 1. 50 %
........1 1 9)A T ZERO REF FL A G = HIGH
........1 2 0)A T ZERO SPD FLAG = HIGH
........1 2 1)A T ST ANDSTILL = HIGH
SPINDLE ORIENTATE 4
.......... 1 22)ZERO SPEED LOCK = 0. 00
.......... 2 40)MARKER EN ABLE = DISABLED
.......... 2 41)MARKER OFFSET = 0
.......... 2 42)PO SITIO N REF = 0
.......... 2 43)MARKER FREQ M O N = 0. 00 Hz
.......... 2 44)IN POSITION FLAG = LOW
CALIBRATION 3
........2)RA TED ARM A MPS = 9.6 A MPS #
........3)C URRENT LIMIT(%) = 1 5 0.00 %
........4)RA TED FIELD A MPS = 2.00 A MPS
........5)BA SE RA TED RPM = 1500 RPM
........6)DESIRED MA X RPM = 1500 RPM
........7)ZERO SPD OFFSET = 0.0 0 %
........8)M A X T A CH O V OLTS = 60.00 VOLTS
........9)SPEED FBK TYPE = ARMA TURE V OLTS
ENCODER SC ALING 4
.......... 10)QUA DRATURE ENABLE = ENABLED
.......... 11)EN C ODER LINES = 10 00
.......... 12)MOT/ENC SPD RA TIO = 1.0 000
.......... 13)EN C ODER SIG N = NON-INVERT
........1 4)IR C OMPENSATION = 0.00 %
........1 5)FIELD C UR FB TRIM = 1.0 000
........1 6)ARM V OLTS TRIM = 1.00 00
........1 7)A N A LO G T A CHO TRIM = 1. 0000
........1 8)RATED ARM V OLTS = 460.0 VOLTS
........1 9)EL1/2/3 RA TED A C = 415.0 V OLTS
........2 0)MOTOR 1,2 SELEC T = M O TOR 1
DIAGNOSTICS 2
SPEED LOOP MONITOR 3
........1 2 3)TO TAL SPD REF M N = 0.0 0 %
........1 2 4)SPEED DEMA ND M O N = 0. 00 %
........1 25)SPEED ERROR MO N = 0.00 %
........1 2 6)ARM V OLTS MON = 0.0 V OLTS
........1 2 7)ARM V OLTS % M O N = 0.0 0 %
........1 2 8)B A C K EMF % MON = 0. 00 %
........1 2 9)TA C H O VOLTS MON = 0.00 V OLTS
........1 3 0)MOTOR RPM MON = 0 RPM
........1 3 2)ENC ODER RPM MON = 0 RPM
........1 3 1)SPEED FBK M O N = 0.0 0 %
ARM I LOOP MONITOR 3
........1 3 3)ARM CUR DEM M O N = 0.00 %
........1 34)ARM CUR % M O N = 0.00 %
........1 3 5)ARM CUR A MPS MON = 0.0 A MPS
........1 36)UPPER CUR LIM M N = 0.00 %
........1 37)LO W ER C UR LIM MN = 0.0 0 %
........1 38)A C TUAL UPPER LIM = 0.0 0 %
........1 39)A C TUAL LO W ER LIM = 0.0 0 %
........1 40)O/LO A D LIMIT MON = 150.00 %
........1 41)A T C URRENT LIMIT = LO W
FLD I LOOP MONITOR 3
........1 4 3)FIELD DEMA ND M O N = 0.0 0 %
........1 4 4)FIELD C UR % MON = 0. 00 %
........1 4 5)FLD CUR A MPS MON = 0.0 0 A MPS
........1 4 6)A NGLE O F A DV AN CE = 0 DEG
........1 4 7)FIELD A C TIVE M O N = DIS A BLED
ANALOG IO MONITOR 3
........1 5 0)UIP2 (T2) MON = 0.00 0 VOLTS
........1 5 1)UIP3 (T3) MON = 0.00 0 VOLTS
........1 5 2)UIP4 (T4) MON = 0.00 0 VOLTS
........1 5 3)UIP5 (T5) MON = 0.00 0 VOLTS
........1 5 4)UIP6 (T6) MON = 0.00 0 VOLTS
........1 5 5)UIP7 (T7) MON = 0.00 0 VOLTS
........1 5 6)UIP8 (T8) MON = 0.00 0 VOLTS
........1 5 7)UIP9 (T9) MON = 0.00 0 VOLTS
........1 5 9)A OP1 (T10) M O N = 0. 000 V OLTS
........1 6 0)A OP2 (T11) M O N = 0. 000 V OLTS
........1 6 1)A OP3 (T12) M O N = 0. 000 V OLTS
DIGITAL IO MONITOR 3
........1 62)UIP 234 5678 9 = 00 0000 00
........1 63)DIP 123 4123 4 DIO = 000 000 00
........1 64)DOP 123 TRJSC CIP = 1 0110 000
........1 65) + ARM BRIDGE FL A G = LO W
........1 66)DRIVE ST A RT FLA G = LOW
........1 6 7)DRIVE RUN FLA G = LO W
........1 6 8)RUNNING M O DE MO N = STOP
BLOCK OP MONITOR 3
........2 1)RA MP OP MONIT OR = 0.0 0 %
........4 5)MP OP MONITOR = 0.0 0 %
........1 9 2)REF X C MASTER MN = 0.0 0 %
........4 01)SUM MER1 OP MON = 0.0 0 %
........4 15)SUM MER2 OP MON = 0.0 0 %
........4 2 9)PID1 OP M O NITOR = 0.00 %
........4 5 2)PID2 OP M O NITOR = 0.00 %
........4 75)PROFILE Y OP MO N = 0.0 0 %
........4 8 3)DIAMETER OP M O N = 0.0 0 %
........4 9 4)TO TAL TENSION M N = 0.0 0 %
........5 0 0)TORQ UE DEMA ND M N = 0.00 %
........5 23)PRESET OP M O N = 0.00 %
........5 6 0)LA TC H OUTPUT MON = 0.0 0 %
........5 6 8)FILTER1 OP M O N = 0.0 0 %
........5 7 3)FILTER2 OP M O N = 0.0 0 %
........5 7 8)C O UN TER C O UNT = 0
........5 83)TMR ELAPSED TIME = 0.0 SECS
......169)EL1/2/3 RMS M O N = 0.0 VOLTS
......170)DC KILO W ATTS M ON = 0. 0
MOTOR DRIVE ALARMS 2
......171)SPD TRIP EN A BLE = EN A BLED
......172)SPEED TRIP TOL = 50.0 0 %
...... 173)FLD LOSS TRIP EN = EN A BLED
......174)DOP SCC T TRIP EN = DISABLED
...... 175)MISSIN G PULSE EN = EN A BLED
...... 176)REF EXCH TRIP EN = DIS A BLED
...... 177)O VERSPEED DELA Y = 5.0 SECS
STALL TRIP MENU 3
........1 78)ST ALL TRIP ENBL = ENABLED
........1 79)ST ALL CUR LEVEL = 95.0 0 %
........1 80)ST ALL DEL A Y TIME = 10.0 SE CS
......181)A C TIV E TRIP M O N = 8 100
......182)STORED TRIP MON = 00 00
...... 183)EX T TRIP RESET = EN A BLED
SERIAL LINKS 2
RS232 PORT1 3
........1 87)PORT1 BAUD RA TE = 96 00
........1 88)PORT1 FUNC TION = P ARA M EXC H SELE C T
PARAMETER EXCHANGE 4
DRIVE TRANSMIT 5
DRIVE RECEIVE 5
MENU LIST TO HOST 5
REFERENCE EXCHANGE 4
..........189)REF X C SLV RA TIO = 1.0 000
..........190)REF X C SLV SIGN = NON-IN VERT
..........191)REF X C SLA VE M O N = 0.0 0 %
..........192)REF X C MASTER M N = 0.0 0 %
..........GET FROM = 40 0)Block Di sconnect
PORT1 COMMS LINK 4
..........193)PORT1 GRO UP ID = 0
..........194)PORT1 UNIT ID = 0
..........195)PORT1 ERROR C O DE = 0 001
..........196)P1 D OP3 RTS MODE = DISABLED
DISPLAY FUNCTIONS 2
......REDUCED MENU EN ABLE = DIS A BLED
PASSWORD CONTROL 3
........ENTER PA SSW ORD = 00 00
........ALTER PASSWORD = 0 000
......L A N GUAGE SELECT = 0
SOFTWARE VERSION
APPLICATION BLOCKS 2
SUMMER 1 3
........4 01)SUM MER1 OP MON = 0.0 0 %
........4 02)SUM MER1 SIGN 1 = N O N-IN VERT
........4 03)SUM MER1 SIGN 2 = N O N-IN VERT
........4 04)SUM MER1 RA TIO 1 = 1.0 000
........4 05)SUM MER1 RA TIO 2 = 1.0 000
........4 06)SUM MER1 DIVIDER1 = 1.0 000
........4 07)SUM MER1 DIVIDER2 = 1.0 000
........4 08)SUM MER1 INPU T1 = 0.0 0 %
........4 09)SUM MER1 INPU T2 = 0.0 0 %
........4 10)SUM MER1 INPU T3 = 0.0 0 %
........4 11)SUM MER1 DEA DBA ND = 0.00 %
........4 12)SUM MER1 OP INVRT = NON-IN VERT
........4 13)SUM MER1 CLAMP = 10 5.00 %
SUMMER 2 3
........4 15)SUM MER2 OP MON = 0.0 0 %
........4 16)SUM MER2 SIGN 1 = N O N-IN VERT
........4 17)SUM MER2 SIGN 2 = N O N-IN VERT
........4 18)SUM MER2 RA TIO 1 = 1.0 000
........4 19)SUM MER2 RA TIO 2 = 1.0 000
........4 20)SUM MER2 DIVIDER1 = 1.0 000
........4 21)SUM MER2 DIVIDER2 = 1.0 000
........4 22)SUM MER2 INPU T1 = 0.0 0 %
........4 23)SUM MER2 INPU T2 = 0.0 0 %
........4 24)SUM MER2 INPU T3 = 0.0 0 %
........4 25)SUM MER2 DEA DBA ND = 0.00 %
........4 26)SUM MER2 OP INVRT = NON-IN VERT
........4 27)SUM MER2 CLAMP = 10 5.00 %
PID 1 3
........4 29)PID1 OP M O NITOR = 0.0 0 %
........4 30)PID1 INPUT1 = 0.00 %
........4 31)PID1 RA TIO 1 = 1.000 0
........4 32)PID1 DIVIDER1 = 1.0 000
........4 33)PID1 INPUT2 = 0.00 %
........4 34)PID1 RA TIO 2 = 1.000 0
........4 35)PID1 DIVIDER2 = 1.0 000
........4 36)PID1 PROP G AIN = 1.0
........4 37)PID1 IN TEGRAL T C = 5.0 0 SEC S
........4 38)PID1 DERIV TC = 0.0 00 SEC S
........4 39)PID1 FILTER TC = 0.1 00 SECS
........4 40)PID1 IN T PRESET = DIS A BLED
........4 41)PID1 PRESET V AL = 0.0 0 %
........4 42)PID1 RESET = DIS A BLED
........4 43)PID1 POS CLA MP = 1 00.00 %
........4 44)PID1 NEG CL A MP = -10 0.00 %
........4 45)PID1 OUTPU T TRIM = 0. 200 0
........4 46)PID1 PROFL MO DE = 0
........4 47)PID1 MIN PROP G N = 20.00 %
........4 48)PID1 X-A XIS MIN = 0.0 0 %
........PID1 X-A XIS GET FRO M = 40 0)Block Disconnect
........4 49)PID1 PROFILED GN = 0.0
........4 50)PID1 CLAMP FLAG = LO W
........4 51)PID1 ERROR MON = 0.0 0 %
PID 2 3
........4 52)PID2 OP M O NITOR = 0.0 0 %
........4 53)PID2 INPUT1 = 0.00 %
........4 54)PID2 RA TIO 1 = 1.000 0
........4 55)PID2 DIVIDER1 = 1.0 000
........4 56)PID2 INPUT2 = 0.00 %
........4 57)PID2 RA TIO 2 = 1.000 0
To Next Page
Loading...
