CHA NGE PARA METERS 91
6.6.2 SPEED REF SUMMER / Internal speed reference 1 PIN 62
Default connection to the motorised potentiometer output.
6.6.3 SPEED REF SUMMER / Auxiliary speed reference 2 PIN 63
6.6.4 SPEED REF SUMMER / Speed reference 3 monitor PIN 64
T3 is internally connected via UIP3 to 64)SPEED REF 3 MON, so this behaves as a monitor of T3 IP value.
This parameter is not adjustable from the keys. It has the fastest sample rate for rapid response applications.
Note. When 97)SPD BYPASS CUR EN is ENABLED this monitor is set to zero. Use 133)ARM CUR DEM M ON.
6.6.5 SPEED REF SUMMER / Ramped speed reference 4 PIN 65
The factory default is to the run mode ramp block output, so this behaves as a monitor for this value.
6.6.6 SPEED REF SUMMER / Speed/Current Reference 3 sign PIN 66
SPEED REF SUMMER 3
62)INT SPEED REF 1
62)INT SPEED REF 1
0.00 %
PARA METER RANGE DEFAULT PIN
INT SPEED REF 1 + /-105.00 % 0.00% 62
Sets internal reference 1 level.
R R
SPEED REF SUMMER 3
63)SPEED REF 2
63)SPEED REF 2
0.00 %
PARA METER RANGE DEFAULT PIN
SPEED REF 2 + /-105.00% 0.00% 6 3
Sets aux speed reference 2
level. Default connection to T2.
RR
SPEED REF SUMMER 3
65)RA MPED SPD REF 4
65)RA MPED SPD REF 4
0.00 %
PARA METER RANGE DEFAULT PIN
RA MPED SPD REF 4 + /-105.00 % 0.00 % 65
Sets speed reference 4 level.
Default via ramp block from T4
RR
SPEED REF SUMMER 3
66)SPD/CUR REF3 SIGN
66)SPD/CUR REF3 SIGN
N ON-INVERT
PARA METER RANGE DEFAULT PIN
SPD/CUR REF3 SIGN INVERT / NO N-INVERT N ON-INVERT 66
Inverts the speed/current
reference 3.
RR
SPEED REF SUMMER 3
64)SPEED REF 3 MON
64)SPEED REF 3 MON
0.00 %
PARA METER RANGE DEFAULT PIN
64)SPEED REF 3 MON + /-105.00 % 0.00 % 64
Monitors speed ref 3 level
Permanent connection to T3.
R
R
