CONFIGURA TION 177
13.3.1.9 UIPX SETUP / UIP(2) to (9) Digital input, high value for output 1 PIN 3(2)5 to 3(9)5
Note. You can make a simple A ND gate by selecting this as the target PIN of a logical GOTO.
13.3.1.10 UIPX SETUP / UIP(2) to (9) Digital input, low value for output 1 PIN 3(2)6 to 3(9)6
Note. You can make a simple OR gate by selecting this as the target PIN of a logical GO TO.
13.3.1.11 UIPX SETUP / UIP(2) to (9) Digital input, high value for output 2 PIN 3(2)7 to 3(9)7
Note. You can make a simple A ND gate by selecting this as the target PIN of a logical GOTO.
13.3.1.12 UIPX SETUP / UIP(2) to (9) Digital input, low value for output 2 PIN 3(2)8 to 3(9)8
Note. You can make a simple OR gate by selecting this as the target PIN of a logical GO TO.
13.3.1.13 UIPX SETUP / UIP(2) to (9) Threshold PIN 3(2)9 to 3(9)9
E. g. If the range input is set to 20 or 30V, then a threshold of 15.000 V will cause the output to go high for
signals greater than + 15.000 V and low for signals less than or equal to + 15.000V.
The threshold is algebraic. Hence a threshold of –1.000 V will give a high for an input of –0.999 V.
UIP2 (T 2) SETUP 4
325)UIP2 HI V AL OP1
325)UIP2 HI V AL OP1
0.01%
PARA METER RA NGE DEFAULT PIN
UIP2 HI V AL OP1 + /- 300.00% 0.01% 325
Sets the OP1 value selected by
a high UIPX input.
UIP2 (T 2) SETUP 4
326)UIP2 LO V AL OP1
326)UIP2 LO V AL OP1
0.00%
PARA METER RA NGE DEFAULT PIN
UIP2 LO V AL OP1 + /- 300.00% 0.00% 326
Sets the OP1 value selected by
a lo w UIPX input.
UIP2 (T 2) SETUP 4
327)UIP2 HI V AL OP2
327)UIP2 HI V AL OP2
0.01%
PARA METER RA NGE DEFAULT PIN
UIP2 HI V AL OP2 + /- 300.00% 0.01% 327
Sets the OP2 value selected by
a high UIPX input.
UIP2 (T 2) SETUP 4
328)UIP2 LO V AL OP2
328)UIP2 LO V AL OP2
0.00%
PARA METER RA NGE DEFAULT PIN
UIP2 LO V AL OP2 + /- 300.00% 0.00 % 32 8
Sets the OP2 value selected by
a lo w UIPX input.
UIP2 (T 2) SETUP 4
329)UIP2 THRESHOLD
329)UIP2 THRESHOLD
6.000 V OLTS
PARA METER RA NGE DEFAULT PIN
UIP2 THRESH OLD + /- 30.000 V 6.000 V 329
Sets the threshold to determine
the logic high/low for UIPX.
