Typographical Conventions
All examples of user interface texts are printed using 8 pt Arial
Black, e.g.
Selected port: ET: TCi(mea)
All front panel texts (fixed texts on MC5P’s cover) are printed
using 8 pt Eurostile, e.g.
Connectors marked T/C, Low V
Function and Menu keys are often referred to using both the key
name in 8 pt Eurostile and the corresponding text (function)
displayed on the screen in 8 pt Arial Black, e.g.
Function key D/Menu
Unpacking and Inspection
At the factory each new MC5P passes a careful inspection. It should
be free of scrapes and scratches and in proper operation order
upon receipt. The receiver should, however, inspect the unit for any
damage that may have occurred during transit. If there are signs of
obvious mechanical damage, package contents are incomplete, or
the instrument does not operate according to specifications, con-
tact the purchasing sales office as soon as possible. The standard
accessories are as follows:
• Calibration Certificate
• This User Guide
• Warranty Card
• Computer communication cable
• If any internal pressure modules are present:
A pressure hose set
• Two test leads and clips
• If the ET module is present: Four additional test leads and
two clips
For a description of available hardware and software options, see
MC5P’s Modularity and Options on page 20.
If you have to return MC5P to the factory for any reason, pack it
carefully. Include a detailed description of the reason for the return.
Warning!
The accessory polyurethane hose supplied with the calibrator
is rated to the maximum pressure of 20 bar at 21°C (290 psi at
70°F). Applying higher pressure can be hazardous.
