20
General
MC5P’s Modularity and Options
MC5P includes several optional modules both in hardware and firm-
ware. This makes it possible to buy a calibrator with capabilities
according to current requirements. If additional needs arise later
on, add more modules to your MC5P and you will have a tool that
suits all demands.
Hardware modules/options
All MC5P’s are built around the Base Unit (BU). All other modules
are optional, but at least one of the optional hardware modules has
to be available in order to measure/generate/simulate a signal.
1)
E module’s HART communication requires that the respective
firmware option is installed.
2)
Max. 9 Internal Pressure Modules.
MODULE DESCRIPTION
Base Unit (
BU
)
and…
… the Electrical
Module (
E
)
Required module. Includes the case,
display, keyboard, battery pack, common
electronics and the ENV, AUX and
COMP/PRT connectors as well as a
connector for an external pressure module
(
PX1
).
Voltage, low voltage, current and frequency
measurement. Also pulse counting, switch
testing, HART communication
(1
, current
generation, and 24 V loop supply.
Internal Pressure
Modules
(2
(
PM
’s)
Modules with positive and compound gauge
pressure measurement capability and a
barometric module enabling also absolute
pressure measurement together with other
modules.
External Pressure
Module connector
(
EXT
’s)
Connection for external modules capable of
measuring high pressures up to 1000 bar
(approx. 14500 psi).
Electrical and
Temperature
Module (
ET
) and…
… the Internal
Reference
Junction Module
(
RJ
)
Resistance, RTD and thermocouple
measurement/simulation. Low voltage
measurement/generation. Voltage, current,
frequency and pulse generation.
Internal reference junction compensation for
thermocouple measurement/simulation.
Cannot be used without the
ET
Module.
