Advanced Operation and Configuration
Displaying Values in Percentage
In Percentage Display Mode the
measured/generated/simulated
values are displayed as percent-
age of a user defined range. Start
the Percentage Display Mode as
described in chapter Display
Mode Settings on page 76 and en-
ter the Measured Range. The true
value is displayed in the Extra Info
row.
Displaying Error Values
The Error Display Mode utilizes
both of Basic Mode’s windows. The
measured/generated/simulated
values of both windows are treated
as percentages of user defined
ranges. The input value is consid-
ered as the “correct” value and the
output value should follow the in-
put value, while taking the Trans-
fer Function into account. The
window from which Error Display
Mode is invoked is considered as
the instrument’s output signal and
the other window as the input sig-
nal.
Start the Error Display Mode as described in chapter Display Mode
Settings on page 76. Enter the Measured Range for both the in-
put and the output signal, the Error Calculation Method and the
Transfer Function (input/output correlation).
The true output value is displayed in the Extra Info row.
Note.
The Error Display Mode is only available for a Basic Mode window
set for measuring a quantity.
PERCENTAGE
