Phases of Instrument Calibration
The picture gives a general view of the phases in a calibration
procedure. MC5P supports three separate guide texts (white
blocks in the picture):
One is displayed when starting the calibration.
Another when the adjustment utility is started.
The third text is displayed when ending the calibration.
The guide texts may be entered in MC5P or they may be down-
loaded from a PC with a calibration software.
Start
As Found test
Save As
Found results
No. of
repeats
done?
Read Starting
Guide Text
no
yes
Adjustment
required?
Within
limits?
As Left test
Adjustment
* If it is not possible
to adjust the
maximum error
below the "
Reject if
"
limit, consider
replacing the
instrument with
a more accurate
one.
Read Adjusting
Guide Text
no
no*
yes
yes
End
Save As Left
results
No. of
repeats
done?
Read Finishing
Guide Text
no
yes
