BEAMEX MC5P - Modules; Pressure Modules (INT & EXT)

148
Appendix 2, Technical Data
Modules
Pressure Modules (PM & EXT)
1)
Uncertainty includes reference standard uncertainty, hysteresis, non-linearity, repeatability and typical long term stability for
mentioned period. (k=2)
2)
Every internal/external pressure module’s range may be displayed also in absolute pressure if the Barometric Module (PM B)
is installed.
Supports the following pressure units as standard: Pa, hPa, kPa, MPa, mbar, bar, lbf/ft
2
, psi, gf/cm
2
, kgf/cm
2
, kgf/m
2
, kp/cm
2
, at,
mmH
2
O, cmH
2
O, mH
2
O, iwc, ftH
2
O, mmHg, cmHg, mHg, inHg, mmHg(0°C), inHg(0°C), mmH
2
O(4°C), inH
2
O(4°C), ftH
2
O(4°C),
inH
2
O(60°F), mmH
2
O(68°F), inH
2
O(68°F), ftH
2
O(68°F), torr, atm.
Pressure modules 20 bar and below, pressure connection G 1/8 (ISO 228/1) 60° internal cone.
PM60, PM100, PM160 module pressure connection G 1/8 (ISO 228/1) female.
EXT60, EXT100, EXT160, EXT250, EXT600, EXT1000 pressure module pressure connection G 1/4 (ISO 228/1) male.
Wetted parts AISI316 stainless steel, Hastelloy, Nitrile rubber.
In the PM20C, EXT20C, PM60, EXT60, PM100, EXT100, PM160, EXT160, PM250 and EXT250 the maximum overpressure is
twice the range. The maximum overpressure for PM600 and EXT600 is 900 bar and for EXT1000 1100 bar.
Internal
Modules
External
Modules
Unit Range
(2
Resolution 90 Days Uncertainty
(1
(±) 1 Year Uncertainty
(1
(±)
PM B EXT B kPa a
mbar a
psi a
80 to 120
800 to 1200
11.6 to 17.4
0.01
0.1
0.001
-
-
-
0.05 kPa
0.5 mbar
0.0073 psi
PM100m EXT100m kPa
mbar
iwc
0 to 10
0 to 100
0 to 40
0.0001
0.001
0.001
0.025% RDG + 0.025% FS 0.04% RDG + 0.025% FS
PM400mC EXT400mC kPa
mbar
iwc
-40 to 40
-400 to 400
-160 to 160
0.001
0.01
0.001
0.025% RDG + 0.02% FS 0.04% RDG + 0.02% FS
PM1C EXT1C kPa
bar
psi
-100 to 100
-1 to 1
-14.5 to 15
0.001
0.00001
0.0001
0.025% RDG + 0.01% FS 0.04% RDG + 0.01% FS
PM2C EXT2C kPa
bar
psi
-100 to 200
-1 to 2
-14.5 to 30
0.001
0.00001
0.0001
0.025% RDG + 0.01% FS 0.04% RDG + 0.01% FS
PM6C EXT6C kPa
bar
psi
-100 to 600
-1 to 6
-14.5 to 90
0.01
0.0001
0.001
0.025% RDG + 0.01% FS 0.04% RDG + 0.01% FS
PM20C EXT20C kPa
bar
psi
-100 to 2000
-1 to 20
-14.5 to 300
0.01
0.0001
0.001
0.025% RDG + 0.01% FS 0.04% RDG + 0.01% FS
PM60 EXT60 kPa
bar
psi
0 to 6000
0 to 60
0 to 900
0.1
0.001
0.01
-
-
-
0.04% RDG + 0.01% FS
PM100 EXT100 MPa
bar
psi
0 to 10
0 to 100
0 to 1500
0.0001
0.001
0.01
-
-
-
0.04% RDG + 0.01% FS
PM160 EXT160 MPa
bar
psi
0 to 16
0 to 160
0 to 2400
0.0001
0.001
0.01
-
-
-
0.04% RDG + 0.013% FS
PM250 EXT250 MPa
bar
psi
0 to 25
0 to 250
0 to 3700
0.001
0.01
0.1
-
-
-
0.04% RDG + 0.015% FS
PM600 EXT600 MPa
bar
psi
0 to 60
0 to 600
0 to 9000
0.001
0.01
0.1
-
-
-
0.04% RDG + 0.015% FS
- EXT1000 MPa
bar
psi
0 to 100
0 to 1000
0 to15000
0.001
0.01
0.1
-
-
-
0.04% RDG + 0.015% FS
