Calibration
Calibrating an Instrument
Selecting the Instrument to Be Calibrated
To move from Basic Mode to Cali-
bration Mode, press the A/Calibr-
ation Mode Function Key. A list of
instruments available in MC5P’s
memory is presented. If you do not
have any instrument data in
MC5P’s memory, either download
them from a calibration software or
create instruments in MC5P as de-
scribed in chapter Adding New In-
struments on page 124. The Posi-
tion ID / Device ID of an already
calibrated instrument is tick-marked
( ).
When you move the cursor (the inverted text), the additional data
presented in the lower part of the screen changes to reflect the data
of the current instrument.
Select one of the available instruments by pressing the , or
the C/Select key.
Note.
If there are a lot instrument data in MC5P’s memory, displaying the
list may take a few seconds.
11.11.2003 12:32
POSITION/DEVICE ID
101-XI-001.1
112-TT-003.1
112-TT-007.1
PT101.6
PT112.12
PT115.15-1
PT115.15-2
PT112.16
TT112.08
TT112.10
TT112.12
Device ID
Position Name
Calibrated
TT112.07
Intake Temperature on Feed 1
Not Calibrated
Mode
Basic
MENUSelect
To Next Page
