19
Drop Down Lists
Drop Down Lists are used when
there is a limited amount of preset
values. You have to select one of the
available options. The list of avail-
able options is displayed either be-
low or above the Drop Down List field.
A Drop Down List opens when you press the key or any of the
numeric keys or the C/Edit Function Key available in some configu-
ration windows. Small arrows in the upper right and/or lower right
corner indicates that the list is longer than the visible part.
Use either the cursor keys and or the and keys to scroll
through the available options. Select one of the options with the
key or the key..
Pop-up Lists
Pop-up Lists are similar to Drop Down Lists except that Pop-up
Lists appear in conjunction with menus. There’s a picture of a Pop-
up List in chapter The User Interface on page 14.
Scrolling a Pop-up List can be done with an additional way (com-
pared Drop Down Lists): Each time you push the numeric menu
key that opened the Pop-up List, the cursor advances one step.
Selection Lists
Selection lists are used when you
have to choose one of several op-
tions. Selection lists are often large,
thus almost reserving the whole
window.
Selection lists can be longer than
the visible part. When the cursor
(the row with the inverted text) is
on the bottom and you press the
key, the list scrolls and displays
more options.
The and keys scroll the list
one line at a time. The and
keys to scroll the list one page at a
time (if applicable).
Select one of the options with the C/Select Function Key or either
the key or the key..
Measured
Input Method
Measured
Keyed
Controlled
Measured
Input Method
10.11.2003 15:18
POSITION/DEVICE ID
101-XL-001.1
112-TT-003.1
ESw
PT106.1
PT112.12
PT112.15-1
PT112.15-2
PT112.16
TI
112-TT-007.1
Basic
Mode
MENU
VV
Device ID
TT112.09
Position Name
Product temperature
Calibrated
22.02.2000
Select
