Note.
The accuracy of the “Opened @” and “Closed @” values depend
greatly on the change rate of the switch’s input signal.
Hint.
If you use MC5P to generate/simulate the switch’s input signal, you
can use ramping to create changing input signals for the switch
under test.
Where to find more information when measuring a switch’s input signal…
Pressure Measurement on page 35
Using External Modules on page 35
Voltage Measurement on page 38
Current Measurement on page 37
Thermocouple Measurement (Temperature) on page 47
RTD Measurement (Temperature) on page 46
Where to find more information when generating a switch’s input signal…
Voltage Generation on page 58
Current Generation on page 56
Thermocouple Simulation on page 63
Ramping on page 67
