48
Startup and Basic Operation
Note.
MC5P has a comprehensive set of predefined sensor types. Addi-
tional sensor types are available as options.
Warning!
If you connect an RTD sensor to the ET module’s R, RTD con-
nectors, there is no galvanic isolation between the thermo-
couple and the RTD sensor.
Next…
Thermocouple Simulation on page 63
RTD Measurement (Temperature) on page 46
Voltage Measurement on page 38
Special Measurements on page 49.
Alarm Limit Settings on page 69.
Calibration, see Part D.
Problems with thermovoltage measurement? See Error situations
on page 96.
