7-20 îš¡ Adding Objects
Setting bar code dimensions
Choose the Dimension tab on the Bar Code screen to set bar code measurements:
Figure 7-12. The Bar Code screen, Dimensions tab.
Use the Dimension tab to set these bar code options:
Height Set the bar code height (in the unit of measure
specified on the System Setup screen Localization
tab) by entering a height or choosing from the
options list.
Hint! If you want to make a bar code taller,
setting the height here is preferable to using the
Height option on the Bar Code Size and Location
tab.
Density Set the density in mils by choosing from this list.
The density is the thickness of the bars and how far
apart they are.
Hint! This setting determines the width of the
bar code.
Ratio Set the width ratio by choosing from this list. Ratio
determines the relative width of the wide bars to the
narrow bars in the bar code.
