2-4
îš¡
Installing sup
plies
Opening the printer
St
e
p
1
:
T
o open the printer
, squeeze the release bar
.
St
e
p
2
:
Raise the printer cover up
and away to the right.
Figure
2-2. Openin
g the printer
.
Make sure all internal packing material
s have been removed
before you proceed.
Cover release
bar
24
26
