Brother MFC-9340CDW - Page 189

3-26
Confidential
Disassembly/Re-Assembly (second)
8.9 Manual Feed
Slot Cover ASSY
5/5
8.49 External
Temperature/
Humidity Sensor
PCB ASSY
15/30
8.51 Main PCB
ASSY
40/60
8.52 Develop
Release Clutch
30/50
8.53 Process
Drive Unit
70/90
8.54 Fuser
Drive Gear Z25
5/5
8.55 Registration
Clutch
20/30
8.56 Paper
Feed Clutch
20/30
8.57 Main Drive
Unit
120/140
8.60 Paper
Feed Unit
10/10
8.58 Roller
Holder ASSY
5/10
8.66 High-voltage
Power Supply
PCB ASSY/
HVPS Flat Cable
65/60
8.67 Main Fan
5/10
8.68 Develop
Release Sensor
PCB ASSY
5/5
8.40 Document
Scanner Unit
30/40
8.41 Panel
Control PCB ASSY
70/70
8.42 Touch
Panel
ASSY/LCD
45/45
8.47 Back Cover
Lower
5/5
8.69 Low-voltage
Power Supply
PCB ASSY
30/30
8.64 Back Cover
Sensor Harness
ASSY
5/5
8.61 Paper Eject
ASSY
10/15
8.62 Back Cover
Upper
45/45
8.63 Exit Roller
Bushing/
Eject Roller ASSY
10/15
8.50 Wireless
LAN Cap/
Wireless LAN
PCB ASSY
10/10
8.43 First Side
CIS Unit/
First Side CIS
Flat Cable
135/145
8.59 USB Host
PCB ASSY/
Inner Front
Cover
85/85
8.40 Control
Panel ASSY
50/50
8.48 Duplex Tray
(2-sided Printing
Model Only)
30/30
