Brother MFC-9340CDW Service Manual

5-61
Confidential
TTLCOPY:00000000 Number of copy pages
CL_COPY:00000000 Number of color copy pages
MN_COPY:00000000 Number of monochrome copy pages
TTLPCPT:00000000 Number of PC prints made
CL_PCPT:00000000 Total number of PC color printed pages
MN_PCPT:00000000 Total number of PC monochrome printed pages
TTLFAX:00000000 Number of List/FAX outputs made
CL_FAX:00000000 Total number of color List/FAX printed pages
MN_FAX:00000000 Total number of monochrome List/FAX printed pages
CCVRGUSI:4.32% Average coverage of cyan toner cartridge in use
CCVRGACC:3.47% Accumulated average coverage of cyan toner cartridge
MCVRGUSI:4.32% Average coverage of magenta toner cartridge in use
MCVRGACC:3.47% Accumulated average coverage of magenta toner cartridge
YCVRGUSI:4.32% Average coverage of yellow toner cartridge in use
YCVRGACC:3.47% Accumulated average coverage of yellow toner cartridge
KCVRGUSI:4.32% Average coverage of black toner cartridge in use
KCVRGACC:3.47% Accumulated average coverage of black toner cartridge
CDRUM:00000000 Number of cyan drum rotations
MDRUM:00000000 Number of magenta drum rotations
YDRUM:00000000 Number of yellow drum rotations
KDRUM:00000000 Number of black drum rotations
CTN_RND: 00000000 Number of cyan developer roller rotations
MTN_RND: 00000000 Number of magenta developer roller rotations
YTN_RND: 00000000 Number of yellow developer roller rotations
KTN_RND: 00000000 Number of black developer roller rotations
MN_PG:00000000 Number of pages printed on paper fed from manual feed slot
TR1_PG:00000000 Number of pages printed on paper fed from paper tray
DX_PG:00000000 Number of sheets where two-sided are printed
A4+LTR:00000000 Total of pages printed on A4 and letter size paper
LG+FOL:00000000 Total of pages printed on legal and folio size paper
B5+EXE:00000000 Total of pages printed on B5 and EXE size paper
ENVLOP:00000000 Number of pages printed on envelopes
A5 :00000000 Number of pages printed on A5 size paper
OTHER :00000000 Total of pages printed on paper other than the above
PLTNRE:00000000 Total of pages printed on plain, thin, and recycled paper
TKTRBD:00000000 Total of pages printed on thick, thicker paper and bond paper
ENVTYP:00000000 Total of pages printed on envelopes, envelopes (thick), and
envelopes (thin)
LABEL:00000000 Number of pages printed on label
LCD Description

Brother MFC-9340CDW Specifications

Printing Specifications

print speed (black)	up to 23 ppm
print speed (color)	up to 23 ppm
print resolution	up to 600 x 2400 dpi
automatic duplex printing	Yes

Copying Specifications

copy speed (black)	up to 23 cpm
copy speed (color)	up to 23 cpm
copy resolution	600 x 600 dpi
copy reduction/enlargement	25% - 400% in 1% increments

Scanning Specifications

scanner type	Color Flatbed with ADF
document glass size	8.5” x 11.7”
scan resolution (optical)	1200 x 2400 dpi
scan resolution (interpolated)	19200 x 19200 dpi

Fax Specifications

fax modem	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Memory and Interfaces

memory (standard/max)	192MB / 192MB
standard interfaces	Wireless 802.11b/g/n, Ethernet, Hi-Speed USB 2.0
usb direct interface	Yes

Supplies and Accessories

black toner cartridge yield	2, 500 pages
cyan toner cartridge yield (standard)	1, 400 pages
magenta toner cartridge yield (standard)	1, 400 pages
yellow toner cartridge yield (standard)	1, 400 pages
cyan toner cartridge yield (high capacity)	2, 200 pages
magenta toner cartridge yield (high capacity)	2, 200 pages
yellow toner cartridge yield (high capacity)	2, 200 pages
drum unit yield	15, 000 pages
belt unit yield	50, 000 pages
waste toner box yield	50, 000 pages
multi-purpose paper	Letter, 500 sheets
