Brother MFC-9340CDW Service Manual

5-62
Confidential
HAGAKI:00000000 Number of pages printed on post card
GLOSSY:00000000 Number of pages printed on glossy paper
TTL_JAM:00000000 Total of jammed sheets
MN_JAM:00000000 Number of sheets jammed in the manual feed slot
TR1_JAM:00000000 Number of sheets jammed in the paper tray
IN_JAM:00000000 Number of sheets jammed inside the machine
RE_JAM:00000000 Number of sheets jammed in paper eject section and back cover
DX_JAM:00000000 Number of sheets jammed during two-sided printing
POWER:00000375 Total hours of current conduction
PWRCNT:00000000 Number of times that the power is turned ON
MACERR_01:0000
*3
Machine error history (Past 10 error history)
CTN_CH:0000
*4
Number of times that the cyan toner cartridge has been replaced
MTN_CH:0000
*4
Number of times that the magenta toner cartridge has been
replaced
YTN_CH:0000
*4
Number of times that the yellow toner cartridge has been replaced
KTN_CH:0000
*4
Number of times that the black toner cartridge has been replaced
CDRM_CH:0000
*4
Number of times that the cyan drum unit has been replaced
MDRM_CH:0000
*4
Number of times that the magenta drum unit has been replaced
YDRM_CH:0000
*4
Number of times that the yellow drum unit has been replaced
KDRM_CH:0000
*4
Number of times that the black drum unit has been replaced
WTNR_CH:0000
*4
Number of times that the waste toner box has been replaced
BELT_CH:0000 Number of times that the belt unit has been replaced
FUSR_CH:0000
*4
Number of times that the fuser unit has been replaced
PFK1_CH:0000
*4
Number of times that the PF kit 1 has been replaced
CTN_PG1:00000000 Number of pages printed from the currently installed cyan toner
cartridge
CTN_PG2:00000000 Number of pages printed from the previous installed cyan toner
cartridge
MTN_PG1:00000000 Number of pages printed from the currently installed magenta
toner cartridge
MTN_PG2:00000000 Number of pages printed from the previous installed magenta
toner cartridge
YTN_PG1:00000000 Number of pages printed from the currently installed yellow toner
cartridge
YTN_PG2:00000000 Number of pages printed from the previous installed yellow toner
cartridge
KTN_PG1:00000000 Number of pages printed from the currently installed black toner
cartridge
KTN_PG2:00000000 Number of pages printed from the previous installed black toner
cartridge
WTNR_PG:00000000 Number of pages printed from the waste toner box
LCD Description

Brother MFC-9340CDW Specifications

Printing Specifications

print speed (black)	up to 23 ppm
print speed (color)	up to 23 ppm
print resolution	up to 600 x 2400 dpi
automatic duplex printing	Yes

Copying Specifications

copy speed (black)	up to 23 cpm
copy speed (color)	up to 23 cpm
copy resolution	600 x 600 dpi
copy reduction/enlargement	25% - 400% in 1% increments

Scanning Specifications

scanner type	Color Flatbed with ADF
document glass size	8.5” x 11.7”
scan resolution (optical)	1200 x 2400 dpi
scan resolution (interpolated)	19200 x 19200 dpi

Fax Specifications

fax modem	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Memory and Interfaces

memory (standard/max)	192MB / 192MB
standard interfaces	Wireless 802.11b/g/n, Ethernet, Hi-Speed USB 2.0
usb direct interface	Yes

Supplies and Accessories

black toner cartridge yield	2, 500 pages
cyan toner cartridge yield (standard)	1, 400 pages
magenta toner cartridge yield (standard)	1, 400 pages
yellow toner cartridge yield (standard)	1, 400 pages
cyan toner cartridge yield (high capacity)	2, 200 pages
magenta toner cartridge yield (high capacity)	2, 200 pages
yellow toner cartridge yield (high capacity)	2, 200 pages
drum unit yield	15, 000 pages
belt unit yield	50, 000 pages
waste toner box yield	50, 000 pages
multi-purpose paper	Letter, 500 sheets
