Brother MFC-9340CDW Service Manual

2-16
Confidential
4800 After the waste toner sensor
detected that the waste toner
box was almost full, pages more
than the specified number have
been printed.
2-44
4900 ---
4A00 ---
4B01 Dot counter of the toner cartridge
(Black) or develop roller counter
reaches the upper limit soon.
2-45
4B02 Dot counter of the toner cartridge
(Yellow) or develop roller counter
reaches the upper limit soon.
2-45
4B03 Dot counter of the toner cartridge
(Magenta) or develop roller
counter reaches the upper limit
soon.
2-45
4B04 Dot counter of the toner cartridge
(Cyan) or develop roller counter
reaches the upper limit soon.
2-45
4C01 Dot counter of the toner
cartridge (Black) or develop
roller counter has reached the
upper limit was detected.
2-46
4C02 Dot counter of the toner
cartridge (Yellow) or develop
roller counter has reached the
upper limit was detected.
2-46
4C03 Dot counter of the toner
cartridge (Magenta) or develop
roller counter has reached the
upper limit was detected.
2-46
4C04 Dot counter of the toner
cartridge (Cyan) or develop roller
counter has reached the upper
limit was detected.
2-46
4C05 During printing, dot counter of
color toner cartridge or develop
roller counter has reached the
upper limit was detected.
2-46
Error
codes
Problem
Refer
to:
4D01 ---
4E01 ---
4F01 The new toner sensor of the
toner cartridge (Black) could not
detect a new cartridge properly.
2-47
4F02 The new toner sensor of the
toner cartridge (Yellow) could not
detect a new cartridge properly.
2-47
4F03 The new toner sensor of the
toner cartridge (Magenta) could
not detect a new cartridge
properly.
2-47
4F04 The new toner sensor of the
toner cartridge (Cyan) could not
detect a new cartridge properly.
2-47
5001 ---
5002 Printable pages set for the PF kit
1 has reached the upper limit.
2-47
5003 ---
5004 ---
5005 ---
5100 ---
5200 ---
5301 ---
5302 ---
5401 ---
5402 ---
5406 ---
5502 ---
5602 ---
5702 ---
5801 ---
5802 ---
5902 ---
Error
codes
Problem
Refer
to:

Brother MFC-9340CDW Specifications

Printing Specifications

print speed (black)	up to 23 ppm
print speed (color)	up to 23 ppm
print resolution	up to 600 x 2400 dpi
automatic duplex printing	Yes

Copying Specifications

copy speed (black)	up to 23 cpm
copy speed (color)	up to 23 cpm
copy resolution	600 x 600 dpi
copy reduction/enlargement	25% - 400% in 1% increments

Scanning Specifications

scanner type	Color Flatbed with ADF
document glass size	8.5” x 11.7”
scan resolution (optical)	1200 x 2400 dpi
scan resolution (interpolated)	19200 x 19200 dpi

Fax Specifications

fax modem	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Memory and Interfaces

memory (standard/max)	192MB / 192MB
standard interfaces	Wireless 802.11b/g/n, Ethernet, Hi-Speed USB 2.0
usb direct interface	Yes

Supplies and Accessories

black toner cartridge yield	2, 500 pages
cyan toner cartridge yield (standard)	1, 400 pages
magenta toner cartridge yield (standard)	1, 400 pages
yellow toner cartridge yield (standard)	1, 400 pages
cyan toner cartridge yield (high capacity)	2, 200 pages
magenta toner cartridge yield (high capacity)	2, 200 pages
yellow toner cartridge yield (high capacity)	2, 200 pages
drum unit yield	15, 000 pages
belt unit yield	50, 000 pages
waste toner box yield	50, 000 pages
multi-purpose paper	Letter, 500 sheets
