2-17
Confidential
5A02 ---
5B02 ---
5C02 ---
6001 The top cover sensor detected
that the joint cover ASSY was
open.
2-48
6002 ---
6003 ---
6004 The eject sensor detected that
the fuser cover ASSY was open.
2-48
6101 New toner detection terminal not
being conducting caused the
machine to detected that a toner
cartridge (Black) is not set.
2-49
6102 New toner detection terminal not
being conducting caused the
machine to detected that a toner
cartridge (Yellow) is not set.
2-49
6103 New toner detection terminal not
being conducting caused the
machine to detected that a toner
cartridge (Magenta) is not set.
2-49
6104 New toner detection terminal not
being conducting caused the
machine to detected that a toner
cartridge (Cyan) is not set.
2-49
6200 ---
6201 ---
6202 ---
6203 ---
6204 ---
6208 Immediately after power-ON or
the joint cover ASSY was closed,
GRID current error detected that
no drum unit (Color) was set.
2-51
Error
codes
Problem
Refer
to:
6209 Immediately after power-ON or
the joint cover ASSY was
closed, GRID current error
detected that one of the drum
units (Color) was not set.
2-51
620A Immediately after power-ON or
the joint cover ASSY was closed,
GRID current error detected that
no drum unit (Black) was set.
2-51
6300 BCLN terminal current value
detected that no waste toner box
was set.
2-52
6400 The registration mark sensor
detected that no belt unit was
set.
2-53
6602 ---
6701 ---
6801 The internal temperature sensor
detected a temperature higher
than the specified value.
2-54
6802 ---
6901 Some fuser unit errors occurred
at power-ON or upon recovery
from sleep mode.
2-54
6902 After the errors was detected at
the fuser unit, power was turned
ON again and the error is being
checked. (If power is turned OFF
and ON after error code 6901
occurred, this code is displayed
for about 15 minutes.)
2-54
6A00 Electric discharge that may be
caused by dirt on the corona wire
of the drum unit was detected.
2-55
Error
codes
Problem
Refer
to:
