Page #58 background imageLoading...
Page #58 background image
2-19
Confidential
7801 ---
7802 ---
7900 After the manual feed sensor
detects pass of paper fed from
the manual feed slot, the
registration rear sensor does not
detect paper pass after a set
period of time. Or after the
manual feed sensor detects
paper pass, the registration rear
sensor detects paper
pass within a set period of time.
2-60
7C00 ---
7D00 ---
7E00 ---
8401 ---
8402 ---
8501 The paper feed sensor detected
that the paper tray was not set
(
before print registration
in
engine) in 2-sided printing.
2-61
8502 ---
8503 ---
8504 ---
8505 The paper feed sensor detected
that the paper tray was not set
(after print registration in engine)
in 2-sided printing.
2-61
8506 ---
8507 ---
8508 ---
8601 ---
8602 ---
8603 ---
8604 ---
8701 ---
8702 ---
8703 ---
Error
codes
Problem
Refer
to:
8604 ---
8701 ---
8702 ---
8703 ---
8801 ---
8802 ---
8901 ---
8902 ---
8903 The back cover sensor detected
the open state when 2-sided
printing is started (before the
registration of printing in the
engine).
2-61
8904 The back cover sensor detected
the open state during 2-sided
printing (after the registration of
printing in the engine).
2-61
8A01 The registration rear sensor
detected that the fed paper was
larger or smaller than the
specified size in 2-sided printing.
2-62
8A02 ---
8C00 No paper is in the manual feed
slot when printing from the
manual feed slot.
2-62
8D01 The registration rear sensor
detected that the paper loaded in
the paper tray was smaller than
the specified size.
2-63
8D02 When printing with the back
cover closed, the paper size
selected in the print data is
smaller than the valid size.
2-63
8E01 Upon fax reception, the paper
size setting is the one other than
A4, Letter, Legal, and Folio.
2-63
Error
codes
Problem
Refer
to:
