Air conditioning system
133
1 - Shock absorber; 2-Lower mounting bolt
3. Install the rear shock absorber lower
mounting bolts (right and left).
4. Remove the jack from the rear axle.
1 - Lateral thrust rod; 2-Left mounting bolt;
3 - Right mounting nut; 4 - Right mounting
bolt
5. Install the lateral thrust rod onto the
rear axle.
△
! Caution
Do not tighten the nut.
6. Connect the wheel speed sensor and
wire clip.
Front
