CENNTRO LOGISTAR 100 - Page 34

Vehicle body
20
Installation
Schematic diagram
Steps
1. Install the front crossbeam assembly.
2. Install 4 fasteners of the front
crossbeam assembly.
Tightening torque: 65 N·m (6.5 kg·m, 47.0
ft-lbs)
3. Remove the jack.
4. Install the stabilizer bar.
5. Install 2 fasteners of the stabilizer bar
(A).
Tightening torque: 65N·m (6.5kg·m,
47.0ft-lbs)
6. Install the left and right thrust rods.
7. Install 8 fasteners of the left and right
thrust rods.
Tightening torque: 43N·m (4.3kg·m,
31.5ft-lbs)
