Power distribution and control system
444
3. Disconnect the power battery high voltage
wire connection plug-as shown by the arrow-.
4. Disconnect the low voltage connection plug
of the motor control unit - as shown by the arrow
-.
5. Unscrew the fixing screw - as shown by
the arrow - and remove the upper cover
plate of the motor control unit- 1 -.
△
! Caution
When installing the cover plate, confirm that
the sealing strip is installed correctly.
