CENNTRO LOGISTAR 100 - Page 55

Exterior trims
41
1-Knife; 2-Adhesive; 3 – Vehicle body
11. Use a knife to trim the adhesive on
the adhesive portion of the vehicle body to a
thickness of 1-2mm.
△
! Caution
Before using a knife to trim the vehicle
body, wash the adhesive parts of the vehicle
body with alcohol or similar substances to
remove grease from them.
1 - Adhesive; 2-Primer coating
12. When reassembling the glass, remove
the old sealing strips and adhesive from the
glass.
