Cisco ASR 920 series Configuration Guide Ethernet Router

Configuring CFM over EFP Interface with Cross Connect—Single Tag VLAN
Cross Connect
SUMMARY STEPS
1.
enable
2.
configure terminal
3.
interface gigabitethernet slot/subslot/port
4.
service instance id Ethernet [service-name]
5.
encapsulation dot1q {any | vlan-id [vlan-id[-vlan-id]]}
6.
rewrite ingress tag {push {dot1q vlan-id | dot1q vlan-id second-dot1q vlan-id | dot1ad vlan-id dot1q
vlan-id} | pop {1 | 2} | translate {1-to-1 {dot1q vlan-id | dot1ad vlan-id}| 2-to-1 dot1q vlan-id | dot1ad
vlan-id}| 1-to-2 {dot1q vlan-id second-dot1q vlan-id | dot1ad vlan-id dot1q vlan-id} | 2-to-2 {dot1q
vlan-id second-dot1q vlan-id | dot1ad vlan-id dot1q vlan-id}} [symmetric]
7.
xconnect peer-ip-address vc-id {encapsulation {l2tpv3 [manual] | mpls [manual]} | pw-class
pw-class-name }[pw-class pw-class-name] [sequencing {transmit|receive|both}]
8.
cfm mep domain domain-name [up | down] mpid mpid-value [cos cos-value]
DETAILED STEPS
PurposeCommand or Action
Enables privileged EXEC mode.enable
Step 1
Example:
Router> enable
•
Enter your password if prompted.
Enters global configuration mode.configure terminal
Example:
Router# configure terminal
Step 2
Specifies the Gigabit Ethernet interface to configure,
where:
interface gigabitethernet slot/subslot/port
Example:
Router(config)# interface Gi2/0/2
Step 3
slot/subslot/port—Specifies the location of the
interface.
Creates a service instance (an instantiation of an EVC)
on an interface and sets the device into the
config-if-srv submode.
service instance id Ethernet [service-name]
Example:
Router(config-if)# service instance 101 ethernet
Step 4
Configures the encapsulation. Defines the matching
criteria that maps the ingress dot1q, QinQ, or
encapsulation dot1q {any | vlan-id [vlan-id[-vlan-id]]}
Example:
Router(config-if-srv)# encapsulation dot1q 100
Step 5
untagged frames on an interface for the appropriate
service instance.
Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
217
CFM Configuration over EFP Interface with Cross Connect Feature
Configuring CFM over EFP Interface with Cross Connect—Single Tag VLAN Cross Connect
