end
2020#show ethernet service instance id 200 inter gig 0/0/9 platform
Service Instance (EFP) L2 PDU Handing Info
EFP CDP STP VTP DTP PAGP LLDP LACP UDLD LOAM ESMC ELMI PTPPD
RES4 RES5 RES6 RES8 RES9 RESA RESB RESC RESD RESF CFG NH
---------------------------------------------------------------------------------------------------------------------------------------------------------------
Gi0/0/9.Efp200 TUNL TUNL TUNL DROP TUNL TUNL TUNL TUNL TUNL TUNL TUNL TUNL
TUNL TUNL TUNL TUNL TUNL TUNL TUNL TUNL TUNL TUNL Y N
EFP L2PT Tunnel statistics
----------------------------------------
L2protocol Encapped Decapped
----------------------------------------
CDP: 0 0
STP: 4059 13661
VTP: 0 0
DTP: 0 0
PAGP: 0 0
LLDP: 0 0
LACP: 0 0
UDLD: 0 0
LOAM: 0 0
ESMC: 0 0
ELMI: 0 0
PTPPD: 0 0
Layer 2 Protocol Tunnel decap statistics increments on core port for Layer 2 Protocol Tunnel over BD/VPLS
scenario and Layer 2 Protocol Tunnel.
Note
EFPs and Ethernet over Multiprotocol Layer Switching (EoMPLS)
When you configure a pseudowire under a VLAN interface (for example, VLAN 33), the pseudowire becomes
a virtual Layer 2 port in that VLAN (VLAN 33), or bridge domain. In this bridge domain, you can configure
other types of Layer 2 ports, such as EFP portss. Switching functionalities, such as MAC address learning,
flooding, and forwarding to learned MAC addresses, apply to all the Layer 2 ports, including the pseudowire.
When a pseudowire is present in the same bridge domain as an EFP, you cannot configure the EFP with
the rewrite ingress tag pop 2 symmetric service instance configuration command. Other restrictions
about switching between EFPs or between EFPs also still apply.
Note
For more information about configuring pseudowire, see the Cisco ASR 920 Router Chassis Software
Configuration Guide.
Bridge Domain Routing
The switch supports IP routing and multicast routing for bridge domains, including Layer 3 and Layer 2 VPNs,
using the BDI model. There are the limitations:
•
You must configure BDIs for bridge-domain routing.
•
The bridge domain must be in the range of 1 to 4094 to match the supported VLAN range.
Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
38
Ethernet Virtual Connections Configuration
Configuring IEEE 802.1Q Tunneling and Layer 2 Protocol Tunneling Using EFPs
