Cisco ASR 920 series Configuration Guide Ethernet Router

SUMMARY STEPS
1.
enable
2.
configure terminal
3.
ethernet cfm domain domain-name level level-id
4.
service csi-id evc evc-name vlan vlan-id
5.
continuity-check
6.
continuity-check interval time
7.
exit
8.
exit
9.
ethernet evc evc-id
10.
oam protocol {cfm domain domain-name | ldp}
11.
uni count value [multipoint]
12.
exit
13.
Repeat Steps 3 through 12 to define other CFM domains that you want OAM manager to monitor.
14.
interface type number
15.
service instance id ethernet [evc-id]
16.
ethernet lmi ce-vlan map {vlan-id [untagged] | any | default | untagged}
17.
ethernet lmi interface
18.
encapsulation dot1q vlan-id
19.
bridge-domain domain-number
20.
cfm mep domain domain-name mpid mpid-id
21.
exit
22.
service instance service-instance-id ethernet
23.
encapsulation untagged
24.
l2protocol peer
25.
bridge-domain bridge-domain-number
26.
exit
27.
ethernet uni [bundle [all-to-one] | id uni-id | multiplex]
28.
end
DETAILED STEPS
PurposeCommand or Action
Enables privileged EXEC mode.enable
Step 1
Example:
Device> enable
•
Enter your password if prompted.
Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
289
Configuring Ethernet Local Management Interface at a Provider Edge
Configuring Ethernet LMI Interaction with CFM
