Creating Service Instances
Beginning in privileged EXEC mode, follow these steps to create an EFP service instance:
SUMMARY STEPS
1.
configure terminal
2.
interface interface-id
3.
service instance number ethernet [name]
4.
encapsulation {default | dot1q | priority-tagged | untagged}
5.
rewrite ingress tag pop {1 | 2} symmetric
6.
bridge-domain bridge-id [split-horizon group group-id]
7.
end
8.
show ethernet service instance show bridge-domain [n | split-horizon]
9.
copy running-config startup-config
DETAILED STEPS
PurposeCommand or Action
Enter global configuration mode.configure terminal
Step 1
Specify the port to attach to the policy map, and enter interface configuration
mode. Valid interfaces are physical ports.
interface interface-id
Step 2
Configure an EFP (service instance) and enter service instance configuration)
mode.
service instance number ethernet
[name]
Step 3
•
The number is the EFP identifier, an integer from 1 to 4000.
•
(Optional) ethernet name is the name of a previously configured EVC.
You do not need to use an EVC name in a service instance.
Configure encapsulation type for the service instance.encapsulation {default | dot1q |
priority-tagged | untagged}
Step 4
• default—Configure to match all unmatched packets.
• dot1q—Configure 802.1Q encapsulation. See Table 2: Supported
Encapsulation Types for details about options for this keyword.
• priority-tagged—Specify priority-tagged frames, VLAN-ID 0 and CoS
value of 0 to 7.
• untagged—Map to untagged VLANs. Only one EFP per port can have
untagged encapsulation.
(Optional) Specify that encapsulation modification to occur on packets at ingress.rewrite ingress tag pop {1 | 2}
symmetric
Step 5
• pop 1—Pop (remove) the outermost tag.
• pop 2—Pop (remove) the two outermost tags.
Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
21
Ethernet Virtual Connections Configuration
Creating Service Instances
