Cisco ASR 920 series Configuration Guide Ethernet Router

Configuration Examples
This example shows how to configure port-channel interface 1 to be inactive if fewer than 2 member ports
are active in the EtherChannel:
Device> enable
Device# configure terminal
Device(config)# interface port-channel 1
Device(config-if)# lacp min-bundle 2
Device(config-if)# end
Configuring LACP (802.3ad) for Gigabit Interfaces
Perform this task to create a port channel with two bundled ports. You can configure a maximum of four
bundled ports per port channel.
SUMMARY STEPS
1.
enable
2.
configure terminal
3.
interface port-channel number
4.
ip address ip-address mask
5.
exit
6.
interface type slot/subslot/ port
7.
no ip address
8.
channel-group channel-group-number mode {active | passive}
9.
exit
10.
interface type slot/subslot/ port
11.
no ip address
12.
channel-group channel-group-number mode {active | passive}
13.
end
DETAILED STEPS
PurposeCommand or Action
Enables privileged EXEC mode.enable
Step 1
Example:
Device> enable
•
Enter your password if prompted.
Enters global configuration mode.configure terminal
Example:
Device# configure terminal
Step 2
Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
360
Configuring IEEE 802.3ad Link Bundling
Configuring LACP (802.3ad) for Gigabit Interfaces

Cisco ASR 920 series Specifications

General

Form Factor	1RU
Operating System	Cisco IOS XE
Model	ASR 920 series
Memory	4 GB DRAM
Power Supply	AC or DC
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Relative Humidity	5% to 95% non-condensing
MTBF	Varies by model
Management	CLI, SNMP
