Cisco ASR 920 series Configuration Guide Ethernet Router

PurposeCommand or Action
Bind the attachment circuit to a pseudowire virtual circuit (VC) and
enter cross connect configuration mode.
xconnect peer-router-id vcid pw-class pw-class
name
Example:
Router(config-if-srv)# xconnect
10.10.10.10 123 encapsulation mpls
Step 8
Return to privileged EXEC mode.end
Example:
Router(config-if-srv)# end
Step 9
Configuration Examples
The example shows the C-UNI port.
interface GigabitEthernet0/3/7
ethernet dot1ad uni c-port
service instance 20 ethernet
encapsulation dot1q 20
rewrite ingress tag push dot1ad 30 symmetric
xconnect 2.2.2.2 20 encap mpls
The example shows the S-UNI port.
interface GigabitEthernet0/3/7
ethernet dot1ad uni s-port
service instance 20 ethernet
encapsulation default
rewrite ingress tag push dot1ad 30 symmetric
xconnect 2.2.2.2 20 encap mpls
The example shows the NNI port.
interface GigabitEthernet0/3/7
ethernet dot1ad nni
service instance 20 ethernet
encapsulation dot1ad 20
xconnect 2.2.2.2 20 encap mpls
Verifying IEEE 802.1ad
Use the show ethernet do1adcommands to verify IEEE 802.1ad configuration.
•
show ethernet do1ad
This command displays 802.1ad configuration globally on the router. The following is a sample output
from the command:
Router# show ethernet dot1ad
Interface: GigabitEthernet0/2/1
DOT1AD NNI Port
L2protocol pass
Interface: GigabitEthernet0/2/7
DOT1AD C-Bridge Port
Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
416
Configuring IEEE 802.1ad
Verifying IEEE 802.1ad
