Rewrite Configuration Model for 802.1ad Ports
The table describes the rewrite configuration supported on service instances for the C-UNI, S-UNI and NNI
ports
Egress DirectionIngress DirectionRewritePort
Bridge Domain
Not supportedSupportedPushC-UNI
S-UNI
Not supportedSupportedPopNNI
SupportedNot supportedPush
Trunk EFP
SupportedSupportedPopC-UNI
NANANAS-UNI
Not supportedSupportedPopNNI
SupportedNot supportedPush
Cross Connect
Not supportedSupportedPushC-UNI
S-UNI
NANANANNI
Information About 802.1ad
802.1ad Ports
In 802.1ad, a port is configured as either a customer user-network interface (C-UNI), a service-provider UNI
(S-UNI), or a network-to-network interface (NNI). Only Layer 2 interfaces can be 802.1ad ports.
• C-UNI—an be either an access port or an 802.1Q trunk port. The port uses the customer bridge addresses.
To configure a C-UNI port, enter the ethernet dot1ad uni c-port interface configuration command.
Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
403
Configuring IEEE 802.1ad
Rewrite Configuration Model for 802.1ad Ports

Cisco ASR 920 series Specifications

General

Form Factor	1RU
Operating System	Cisco IOS XE
Model	ASR 920 series
Memory	4 GB DRAM
Power Supply	AC or DC
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Relative Humidity	5% to 95% non-condensing
MTBF	Varies by model
Management	CLI, SNMP
