Cisco ASR 920 series Configuration Guide Ethernet Router

•
The Link Fault Status flag was ignored.
Ethernet Connectivity Fault Management
Ethernet connectivity fault management (CFM) is an end-to-end per-service-instance Ethernet layer OAM
protocol that includes proactive connectivity monitoring, fault verification, and fault isolation. End to end can
be provider edge (PE) to PE or customer edge (CE) to CE. Per service instance means per VLAN.
For more information about Ethernet CFM, see Ethernet Connectivity Fault Management .
How to Set Up and Configure Ethernet Operations Administration
and Maintenance
Enabling Ethernet OAM on an Interface
Ethernet OAM is by default disabled on an interface.
SUMMARY STEPS
1.
enable
2.
configure terminal
3.
interface type number
4.
ethernet oam [max-rate oampdus | min-rate num-seconds| mode {active | passive} | timeout seconds]
5.
exit
DETAILED STEPS
PurposeCommand or Action
Enables privileged EXEC mode.enable
Step 1
Example:
Device> enable
•
Enter your password if prompted.
Enters global configuration mode.configure terminal
Example:
Device# configure terminal
Step 2
Specifies an interface and enters interface
configuration mode.
interface type number
Example:
Device(config)# interface gigabitethernet 0/0/1
Step 3
Carrier Ethernet Configuration Guide (Cisco ASR 920 Series)
304
Using Ethernet Operations Administration and Maintenance
Ethernet Connectivity Fault Management

Cisco ASR 920 series Specifications

General

Form Factor	1RU
Operating System	Cisco IOS XE
Model	ASR 920 series
Memory	4 GB DRAM
Power Supply	AC or DC
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Relative Humidity	5% to 95% non-condensing
MTBF	Varies by model
Management	CLI, SNMP
