Cisco Catalyst 3560-X User Manual

1-20
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
OL-25303-03
Chapter 1 Configuring IP Multicast Routing
Configuring IP Multicast Routing
Configuring Static SSM Mapping
Beginning in privileged EXEC mode, follow these steps to configure static SSM mapping:
For additional information on SSM mapping, see the “Source Specific Multicast (SSM) Mapping”
chapter of the Cisco IOS IP Multicast Configuration Guide, Release 12.4T.
Configuring DNS-Based SSM Mapping
To configure DNS-based SSM mapping, you need to create a DNS server zone or add records to an
existing zone. If the routers that are using DNS-based SSM mapping are also using DNS for other
purposes, you should use a normally configured DNS server. If DNS-based SSM mapping is the only
DNS implementation being used on the router, you can configure a false DNS setup with an empty root
zone or a root zone that points back to itself.
Beginning in privileged EXEC mode, follow these steps to configure DNS-based SSM mapping:
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
ip igmp ssm-map enable Enable SSM mapping for groups in the configured SSM range.
Note By default, this command enables DNS-based SSM mapping.
Step 3
no ip igmp ssm-map query dns (Optional) Disable DNS-based SSM mapping.
Note Disable DNS-based SSM mapping if you only want to rely on
static SSM mapping. By default, the ip igmp ssm-map global
configuration command enables DNS-based SSM mapping.
Step 4
ip igmp ssm-map static access-list
source-address
Configure static SSM mapping.
The ACL supplied for access-list defines the groups to be mapped to the
source IP address entered for the source-address.
Note You can configure additional static SSM mappings. If additional
SSM mappings are configured and the router receives an
IGMPv1 or IGMPv2 membership report for a group in the SSM
range, the switch determines the source addresses associated
with the group by using each configured ip igmp ssm-map
static command. The switch associates up to 20 sources per
group.
Step 5
Repeat Step 4 to configure additional
static SSM mappings, if required.
—
Step 6
end Return to privileged EXEC mode.
Step 7
show running-config Verify your entries.
Step 8
copy running-config startup-config (Optional) Save your entries in the configuration file.
Command Purpose
Step 1
configure terminal Enter global configuration mode.
Step 2
ip igmp ssm-map enable Enable SSM mapping for groups in a configured SSM range.

Cisco Catalyst 3560-X Specifications

General

Enclosure Type	Rack-mountable - 1U
Subtype	Gigabit Ethernet
Ports	48 x 10/100/1000 + 4 x SFP
Flash Memory	64 MB
Power Device	Internal power supply
Voltage Required	AC 120/230 V (50/60 Hz)
Operating System	Cisco IOS
Device Type	Switch
Performance	Switching capacity: 128 Gbps
Jumbo Frame Support	Yes
Routing Protocol	RIP-1, RIP-2, EIGRP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTP, HTTPS
Features	DHCP support, VLAN support, QoS, IPv6 support, Syslog
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad, IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3at
Stacking	Stackable
Security Features	SSH, RADIUS, TACACS+
Management	CLI
Dimensions (H x W x D)	17.5 in
Operating Temperature	32 to 113 °F (0 to 45 °C)
Humidity	10 - 95% (non-condensing)
